Module-Fuel Pump C2 (Standard) Connector End View (D6602B)

Harness-Family: Body

Color: BLUE

Gender: FEMALE

Part Number: 15493509

Part Description: Not Available

Connector No: D6602B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Fuel Pump C2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Fuel Pump C2 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

DB/GY

0.50

FUEL LEVEL SIGNAL 2

N/A

G109

0.75

FUEL LEVEL SENSE RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
