Motor-Seat Adjuster-Driver Horizontal (Memory) Connector End View (D3024A)

Harness-Family: Seat_Cshn_Driver

Color: BLACK

Gender: FEMALE

Part Number: 1379217-3_1379218-2

Part Description: Not Available

Connector No: D3024A

Option: MEMORY

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Motor-Seat Adjuster-Driver Horizontal Connector End View (MEMORY)
GCWD1007372Courtesy of CHRYSLER
Fig 2: Motor-Seat Adjuster-Driver Horizontal Component Location (MEMORY)
GCWD1297910Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 P117 GN/BU 0.75 DRIVER SEAT HORIZONTAL REARWARD DRIVER LHD
2 G491 VT/GY 0.35 DRIVER SEAT HORIZONTAL SENSOR GROUND N/A
4 G401 VT/GN 0.35 DRIVER SEAT HORIZONTAL POSITION SENSE N/A
5 P115 GN 0.75 DRIVER SEAT HORIZONTAL FORWARD DRIVER LHD
(1) Pins not listed are not used for this connector
