Module-Powertrain Control C1 (2.4L) Connector End View (D3821A)

Harness-Family: Dash

Color: BLACK

Gender: FEMALE

Part Number: 1924779-1_2098863-1

Part Description: Not Available

Connector No: D3821A

Option: 2.4L

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Powertrain Control C1 Connector End View (2.4L)
GCWD1085379Courtesy of CHRYSLER
Fig 2: Module-Powertrain Control C1 Component Location (2.4L)
GCWD1297372Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
4 K52 DB/WH 1.0 EVAP PURGE CONTROL N/A
17 B135 DG/GN 0.35 BRAKE SIGNAL 1 N/A
23 F942 PK/VT 0.75 FUSED IGNITION SWITCH OUTPUT (RUN-START) N/A
24 K854 VT/BN 0.50 5 VOLT SUPPLY N/A
25 K175 BN/BU 0.75 RAD FAN CONTROL N/A
26 C13 BU/OG 0.75 A/C CLUTCH CONTROL N/A
27 K51 BN/WH 0.75 ASD RELAY CONTROL N/A
29 K173 BN/VT 0.75 RADIATOR FAN CONTROL SIGNAL N/A
33 D28 YE 0.35 CAN C (-) N/A
41 N7 DB/OG 0.50 FUEL TANK PRESSURE SIGNAL WITH FUEL TANK PRESS
43 T753 DG/YE 0.50 IGNITION CRANK SENSE N/A
45 D511 WH/BG 0.50 LIN BUS N/A
47 N8 DB/PK 0.50 FUEL TANK PRESSURE SENSOR SUPPLY WITH FUEL TANK PRESS
48 K852 GY/BU 0.75 5 VOLT SUPPLY N/A
51 Z909 BK 1.0 GROUND N/A
52 Z909 BK 1.0 GROUND N/A
53 Z909 BK 1.0 GROUND N/A
57 D27 BG/WH 0.35 CAN C (+) N/A
63 K806 DB/BN 0.50 HOOD AJAR SWITCH 2 N/A
64 C18 BU/BN 0.50 A/C PRESSURE SIGNAL N/A
66 B137 DG/BN 0.50 BRAKE PEDAL SENSOR SIGNAL N/A
67 K400 BN/VT 0.75 APP SENSOR GROUND 2 N/A
68 K167 BN/YE 0.75 APP SENSOR GROUND 1 N/A
70 N10 DB/WH 0.50 FUEL TANK PRESSURE SENSOR RETURN WITH FUEL TANK PRESS
71 K31 BN 0.75 FUEL PUMP RELAY CONTROL N/A
72 Z909 BK 1.0 GROUND N/A
73 F342 BN/WH 1.5 FUSED ASD RELAY OUTPUT N/A
74 F342 BN/WH 1.5 FUSED ASD RELAY OUTPUT N/A
75 F342 BN/WH 1.5 FUSED ASD RELAY OUTPUT N/A
76 F342 BN/WH 1.5 FUSED ASD RELAY OUTPUT N/A
77 F342 BN/WH 1.5 FUSED ASD RELAY OUTPUT N/A
87 K914 BN/WH 0.50 SENSOR GROUND N/A
91 K29 WH/BN 0.75 APP SIGNAL 2 N/A
92 K23 BN/WH 0.75 APP SIGNAL 1 N/A
94 K108 VT/GY 0.35 ESIM SIGNAL WITH FUEL TANK PRESS
95 T752 DG/OG 0.50 STARTER RELAY CONTROL N/A
96 A209 RD 1.0 FUSED B(+) N/A
(1) Pins not listed are not used for this connector
