Module-Drive Train Control C1 (Standard) Connector End View (D3872A)

Harness-Family: Under_Body

Color: GREEN

Gender: FEMALE

Part Number: 7283-6453-60

Part Description: Not Available

Connector No: D3872A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Drive Train Control C1 Connector End View (Standard)
GCWD1025425Courtesy of CHRYSLER
Fig 2: Module-Drive Train Control C1 Component Location (Standard)
GCWD1297194Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 D442 WH/DB 0.50 CAN C (+) N/A
2 D443 WH/OG 0.50 CAN C (-) N/A
4 D302 DG 0.35 CAN C (-) N/A
6 K604 BN/BG 0.50 DRIVETRAIN SIGNAL N/A
9 D442 WH/DB 0.50 CAN C (+) N/A
10 D443 WH/OG 0.50 CAN C (-) N/A
11 K504 BN 0.50 DRIVETRAIN 5 VOLT SUPPLY N/A
12 D301 WH 0.35 CAN C (+) N/A
13 F946 PK/GN 0.35 FUSED IGNITION RUN/START CONTROL OUTPUT N/A
15 K594 BN/GN 0.50 DRIVETRAIN SENSOR RETURN N/A
(1) Pins not listed are not used for this connector
