Module-Body Control C4 (Standard) Connector End View (D2762D)

Harness-Family: Dash

Color: BLACK

Gender: FEMALE

Part Number: 15482409_15482404

Part Description: Not Available

Connector No: D2762D

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Body Control C4 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Body Control C4 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

WH/DB

0.50

LICENSE PLATE LAMP DRIVER

N/A

K617

0.50

RUN/START RELAY CONTROL

N/A

K619

BN/OG

0.50

RUN RELAY CONTROL

N/A

L657

WH/GN

0.35

TRAILER TOW TAIL LAMP RELAY CTRL

N/A

G70

VT/BU

0.50

HOOD AJAR SWITCH SENSE

N/A

P305

GN/BU

0.35

ACCESSORY DELAY RELAY CONTROL

N/A

B134

DG/YE

0.75

BRAKE SIGNAL 2

N/A

A947

0.35

FUSED B(+)

N/A

BN/BG

0.50

WASHER FLUID LEVEL SWITCH SENSE

N/A

B20

DG/OG

0.75

BRAKE FLUID LEVEL SIGNAL

N/A

BN/VT

0.35

ELECTRIC WINDSHIELD WIPER DE-ICER CONTROL

N/A

BN/GN

0.75

WIPER HIGH/LOW RELAY CONTROL

N/A

D403

OG/DB

0.35

LIN BUS CBC 3

N/A

L62

WH/YE

0.50

RIGHT REAR TURN LAMP DRIVER

N/A

L61

WH/GN

0.50

LEFT FRONT TURN LAMP DRIVER

N/A

PK/WH

0.50

IGNITION OFF/RUN/START CONTROL OUTPUT

N/A

D46

0.35

CAN C (-)

N/A

D45

0.35

CAN C (+)

N/A

W11

BN/VT

0.50

LOW WASH SW RTN 1

N/A

D145

WH/GN

0.35

CAN IHS (+)

N/A

D146

0.35

CAN IHS (-)

N/A

L304

OG/WH

0.75

RIGHT HIGH BEAM DRIVER

N/A

K90

BU/BG

0.35

STARTER RELAY CONTROL

N/A

B135

DG/GN

0.35

BRAKE SIGNAL 1

N/A

BN/GY

0.75

WIPER PARK SWITCH SENSE

N/A

⁽¹⁾	Pins not listed are not used for this connector
