Passive Entry Lock Switch

Courtesy of CHRYSLER GROUP, LLC

1 - Passive Entry Lock Switch

2 - Wire Harness Connector

REMOVAL

Remove the lamp bar. Refer to LAMP BAR, EXTERIOR HANDLE, REMOVAL AND INSTALLATION .
Disconnect the wire harness connector.
Release the lock tabs and remove the passive entry lock switch from the lamp bar.

INSTALLATION

Follow the removal procedure in reverse for general reassembly of the components on the vehicle. The steps listed below are calling out specific procedures that should be followed during installation.

Verify the lock tabs are fully engage.
