Varistor-Driver Horizontal (Standard) Connector End View (D235202A)

Harness-Family: Seat_Cshn_Driver

Color: NA

Gender: FEMALE

Part Number: 984983

Part Description: Not Available

Connector No: D235202A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Varistor-Driver Horizontal Connector End View (Standard)
GCWD1006464Courtesy of CHRYSLER
Fig 2: Varistor-Driver Horizontal Isometric View (Standard)
GCWD1308482Courtesy of CHRYSLER
Fig 3: Varistor-Driver Horizontal Component Location View (Standard)
GCWD1316146Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 P15 GN/WH 1.0 DRIVER SEAT HORIZONTAL FORWARD DRIVER N/A
2 P17 GN/DG 1.0 DRIVER SEAT HORIZONTAL REARWARD DRIVER N/A
