Microphone-Hands Free-Left (Standard) Connector End View (D3281A)

Harness-Family: Mirror

Color: BLACK

Gender: FEMALE

Part Number: 1-929080-5

Part Description: Not Available

Connector No: D3281A

Option: Standard

Repair Kit Part Number: 68599361AA

Cavity Count: 2

Fig 1: Microphone-Hands Free-Left Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Microphone-Hands Free-Left Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Microphone-Hands Free-Left Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Microphone-Hands Free-Left Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	X807	GY/DG	0.35	EMERGENCY MICROPHONE (-)	EMERGENCY RESPONSE
1	X792	BU/GN	0.35	HANDS FREE MICROPHONE 1 IN (-)	EXCEPT EMERGENCY RESPONSE
2	X712	DG/BU	0.35	HANDS FREE MICROPHONE 1 IN (+)	EXCEPT EMERGENCY RESPONSE
2	X806	GY/BU	0.35	EMERGENCY MICROPHONE (+)	EMERGENCY RESPONSE
