Heater-Forward Facing Camera C2 (Standard) Connector End View (D3942B)

Harness-Family: JUMPER_WINDSHIELD

Color: BLACK

Gender: MALE

Part Number: 6126-ML6T

Part Description: Not Available

Connector No: D3942B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Heater-Forward Facing Camera C2 Connector End View (Standard)
GCWD1255769Courtesy of CHRYSLER
Fig 2: Heater-Forward Facing Camera C2 Isometric View (Standard)
GCWD1318869Courtesy of CHRYSLER
Fig 3: Heater-Forward Facing Camera C2 Component Location View (Standard)
GCWD1318406Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 Z907 BK 0.75 GROUND N/A
