Clutch-A/C Compressor (3.6L Gas) Connector End View (D6655A)

Harness-Family: Powertrain

Color: BLACK

Gender: FEMALE

Part Number: 34062-0047

Part Description: Not Available

Connector No: D6655A

Option: 3.6L GAS

Repair Kit Part Number: 05183448AA

Cavity Count: 2

Fig 1: Clutch-A/c Compressor Connector End View (3.6L GAS)

Courtesy of CHRYSLER

Fig 2: Clutch-A/c Compressor Isometric View (3.6L GAS)

Courtesy of CHRYSLER

Fig 3: Clutch-A/c Compressor Wire Insertion View (3.6L GAS)

Courtesy of CHRYSLER

Fig 4: Clutch-A/c Compressor Component Location View (3.6L GAS)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	C3	DB/YE	0.50	A/C CLUTCH CONTROL OUTPUT	N/A
2	Z907	BK	0.50	GROUND	N/A
