Starter-Eyelet C2 (Standard) Connector End View (D6637B)

Harness-Family: Transmission

Color: BLACK

Gender: FEMALE

Part Number: 2098198-5

Part Description: Not Available

Connector No: D6637B

Option: Standard

Repair Kit Part Number: 68440513AA

Cavity Count: 1

Fig 1: Starter-Eyelet C2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Starter-Eyelet C2 Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Starter-Eyelet C2 Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Starter-Eyelet C2 Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	T750	YE/GY	4.0	STARTER RELAY OUTPUT	N/A
