Lamp-DRL Left (Standard) Connector End View (D2690A)

Harness-Family: Dash

Color: BLACK

Gender: MALE

Part Number: 34899-6120

Part Description: Not Available

Connector No: D2690A

Option: Standard

Repair Kit Part Number: 68535912AA

Cavity Count: 6

Fig 1: Lamp-Drl Left Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Lamp-Drl Left Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Lamp-Drl Left Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Lamp-Drl Left Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	L145	WH/OG	0.75	LEFT SIDE MARKER CONTROL	BASE
1	L551	BG/BN	0.35	LEFT FRONT LIGHTING FAULT SENSE	PREMIUM
2	L61	WH/GN	0.75	LEFT FRONT TURN LAMP DRIVER	N/A
3	Z905	BK	0.75	GROUND	N/A
4	L77	WH/BN	0.75	LEFT FRONT PARK LAMP DRIVER	N/A
5	L58	WH/YE	0.75	LEFT DRL LAMP DRIVER	N/A
6	Z905	BK	0.75	GROUND	N/A
