Solenoid-Fuel Pressure (Standard) Connector End View (D17A)

Harness-Family: Engine_Diesel1

Color: BLACK

Gender: FEMALE

Part Number: 1/14117/87

Part Description: Not Available

Connector No: D17A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Solenoid-Fuel Pressure Connector End View (Standard)
GCWD1204703Courtesy of CHRYSLER
Fig 2: Solenoid-Fuel Pressure Component Location View (Standard)
GCWD1319068Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 K369 BN/RD 0.75 FUEL PRESSURE 12 VOLT SUPPLY N/A
2 K646 GY/GN 0.75 FUEL PRESSURE REGULATOR CONTROL N/A
