Microphone-Hands Free-Right (Standard) Connector End View (D3282A)

Harness-Family: Mirror

Color: BLACK

Gender: FEMALE

Part Number: 1-929080-5

Part Description: Not Available

Connector No: D3282A

Option: Standard

Repair Kit Part Number: 68599361AA

Cavity Count: 2

Fig 1: Microphone-Hands Free-Right Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Microphone-Hands Free-Right Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Microphone-Hands Free-Right Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Microphone-Hands Free-Right Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	X723	BU/BG	0.35	HANDS FREE MICROPHONE 2 IN (-)	N/A
2	X722	BU/DG	0.35	HANDS FREE MICROPHONE 2 IN (+)	N/A
