Heater-Seat Back-Driver (Standard) Connector End View (D6659A)

Harness-Family: Seat_Cushion_Driver

Color: GRAY

Gender: MALE

Part Number: 34899-4081

Part Description: Not Available

Connector No: D6659A

Option: Standard

Repair Kit Part Number: 68510477AA

Cavity Count: 4

Fig 1: Heater-Seat Back-Driver Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Heater-Seat Back-Driver Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Heater-Seat Back-Driver Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Heater-Seat Back-Driver Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	F507	GN/PK	0.75	DRIVER SEAT BACK SUPPLY	N/A
2	P419	OG/BK	0.35	SENSOR RETURN	N/A
3	P415	OG/VT	0.35	DRIVER FRONT HEATED SEAT BACK TEMP SENSE	N/A
4	Z917	BK	0.75	GROUND	N/A
