Switch-Seat Belt Buckle-Rear Right (Standard) Connector End View (D2900A)

Harness-Family: Seat_Rear_Right

Color: BLACK

Gender: MALE

Part Number: 34899-2080

Part Description: Not Available

Connector No: D2900A

Option: Standard

Repair Kit Part Number: 68475549AA

Cavity Count: 2

Fig 1: Switch-Seat Belt Buckle-Rear Right Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Switch-Seat Belt Buckle-Rear Right Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Switch-Seat Belt Buckle-Rear Right Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Switch-Seat Belt Buckle-Rear Right Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	R72	VT/BU	0.75	RIGHT REAR SEAT BELT BUCKLE SWITCH SENSE	N/A
2	R92	GN/BU	0.75	REAR SEAT OCCUPANT DETECTION SENSE RIGHT	N/A
