Speaker-Instrument Panel-Right (Standard) Connector End View (D5916A)

Harness-Family: IP

Color: WHITE

Gender: FEMALE

Part Number: 174463-1

Part Description: .070 SRS MLC 2POS PLUG HOUSING

Connector No: D5916A

Option: Standard

Repair Kit Part Number: 68040489AA

Cavity Count: 2

Fig 1: Speaker-Instrument Panel-Right Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Speaker-Instrument Panel-Right Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Speaker-Instrument Panel-Right Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Speaker-Instrument Panel-Right Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	X208	GY/DG	0.75	AMPLIFIED RIGHT I/P SPEAKER (+)	PREMIUM
1	X202	DG/VT	0.75	RIGHT FRONT SPEAKER (+)	BASE
2	X292	DG/YE	0.75	RIGHT FRONT SPEAKER (-)	BASE
2	X298	GY/GN	0.75	AMPLIFIED RIGHT I/P SPEAKER (-)	PREMIUM
