Solenoid-VVT Intake 2/1 (Standard) Connector End View (D2484A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 805-120-531

Part Description: Not Available

Connector No: D2484A

Option: Standard

Repair Kit Part Number: 68475547AA

Cavity Count: 2

Fig 1: Solenoid-Vvt Intake 2/1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Solenoid-Vvt Intake 2/1 Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Solenoid-Vvt Intake 2/1 Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Solenoid-Vvt Intake 2/1 Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	K78	BN	0.35	CONTROL	N/A
2	Z904	BK	0.35	GROUND	N/A
