Solenoid-EVAP/Purge (Standard) Connector End View (D21A)

Harness-Family: Powertrain

Color: BLACK

Gender: FEMALE

Part Number: 1_928_403_874

Part Description: Not Available

Connector No: D21A

Option: Standard

Repair Kit Part Number: 05143779AB

Cavity Count: 2

Fig 1: Solenoid-Evap/purge Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Solenoid-Evap/purge Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Solenoid-Evap/purge Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Solenoid-Evap/purge Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	K52	DB/WH	0.50	EVAP PURGE CONTROL	N/A
2	Z907	BK	0.50	GROUND	N/A
