Sensor-Side Impact B Pillar-Right (Standard) Connector End View (D3167A)

Harness-Family: Body

Color: NATURAL

Gender: FEMALE

Part Number: 1-1924067-5

Part Description: Not Available

Connector No: D3167A

Option: Standard

Repair Kit Part Number: 68225152AB

Cavity Count: 2

Fig 1: Sensor-Side Impact B Pillar-Right Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Sensor-Side Impact B Pillar-Right Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Sensor-Side Impact B Pillar-Right Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Sensor-Side Impact B Pillar-Right Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	R14	BG/GN	0.75	RIGHT SIDE IMPACT SENSOR 1 SIGNAL	N/A
2	R16	BN/GN	0.75	RIGHT SIDE IMPACT SENSOR 1 GROUND	N/A
