Sensor-Oxygen 1/2 (Standard) Connector End View (D1540A)

Harness-Family: Powertrain

Color: BLACK

Gender: MALE

Part Number: 34899-4080

Part Description: Not Available

Connector No: D1540A

Option: Standard

Repair Kit Part Number: 68510464AA

Cavity Count: 4

Fig 1: Sensor-Oxygen 1/2 Connector End View (Standard)
GCWD1010725Courtesy of CHRYSLER
Fig 2: Sensor-Oxygen 1/2 Isometric View (Standard)
GCWD1010127Courtesy of CHRYSLER
Fig 3: Sensor-Oxygen 1/2 Wire Insertion View (Standard)
GCWD1010376Courtesy of CHRYSLER
Fig 4: Sensor-Oxygen 1/2 Component Location View (Standard)
GCWD1318523Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 K299 BN/WH 0.75 O2 1/2 HEATER CONTROL N/A
2 Z909 BK 0.75 GROUND N/A
3 K904 DB/DG 0.75 O2 RETURN (DOWNSTREAM) N/A
4 K141 DB/YE 0.75 O2 1/2 SIGNAL N/A
