Relay-Stop/Start (Standard) Connector End View (D87903)

Harness-Family: PDC_Underhood

Color: NA

Gender: MALE

Part Number: RELAY_MICRO

Part Description: Not Available

Connector No: D87903

Option: Standard

Repair Kit Part Number: See StarParts

Cavity Count: 5

Fig 1: Relay-Stop/start Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Relay-Stop/start Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
30	T750	INTERNAL	NA	STARTER RELAY OUTPUT	N/A
85	F900	INTERNAL	NA	FUSED IGNITION	N/A
86	K88	INTERNAL	NA	STOP/START RELAY CONTROL	N/A
87	T750	INTERNAL	NA	STARTER RELAY OUTPUT	N/A
