Assembly-Power Distribution Center N6 (Standard) Connector End View (D6630J)

Harness-Family: Dash

Color: NA

Gender: FEMALE

Part Number: 33276569

Part Description: Not Available

Connector No: D6630J

Option: Standard

Repair Kit Part Number: Not Serviceable

Cavity Count: 1

Fig 1: Assembly-Power Distribution Center N6 Connector End View (Standard)
GCWD1007621Courtesy of CHRYSLER
Fig 2: Assembly-Power Distribution Center N6 Isometric View (Standard)
GCWD1008133Courtesy of CHRYSLER
Fig 3: Assembly-Power Distribution Center N6 Component Location View (Standard)
GCWD1318234Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 A10 RD 1.0 FUSED B(+) N/A
