Assembly-Power Distribution Center N5 (Standard) Connector End View (D6630I)

Harness-Family: Dash

Color: NA

Gender: FEMALE

Part Number: 33276568

Part Description: Not Available

Connector No: D6630I

Option: Standard

Repair Kit Part Number: Not Serviceable

Cavity Count: 1

Fig 1: Assembly-Power Distribution Center N5 Connector End View (Standard)
GCWD1007618Courtesy of CHRYSLER
Fig 2: Assembly-Power Distribution Center N5 Isometric View (Standard)
GCWD1006987Courtesy of CHRYSLER
Fig 3: Assembly-Power Distribution Center N5 Component Location View (Standard)
GCWD1318235Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 A13 RD/BN 12 FUSED B(+) N/A
