Antenna-Passive Entry 2 (Standard) Connector End View (D3102A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 2-1438608-1

Part Description: Not Available

Connector No: D3102A

Option: Standard

Repair Kit Part Number: 68057306AA

Cavity Count: 2

Fig 1: Antenna-Passive Entry 2 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Antenna-Passive Entry 2 Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Antenna-Passive Entry 2 Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Antenna-Passive Entry 2 Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	D922	GY/OG	0.35	PASSIVE ENTRY ANTENNA 2 SIGNAL	N/A
2	D923	GY/VT	0.35	PASSIVE ENTRY ANTENNA 2 RETURN	N/A
