Control Cover

WARNING: This page is about a different variant/trim than selected.
CONTROL COVER

INDEX DEPTH
1. Bearing 11mm (0.43in)
2. Pin 14.1mm (0.55in)
3. Seal 1.5mm (0.05in)
GC0181638Courtesy of CHRYSLER GROUP, LLC
