Removal And Installation: Installation

WARNING: This page is about a different car, the 2022 Chrysler Voyager and 2022 Chrysler Pacifica. However, it is still accessible from the selected car via links, so may be relevant.
GC0124791Courtesy of CHRYSLER GROUP, LLC
  1. Position the power seat switch (2) to the seat cushion side shield (3). Gently apply pressure to the switch until the mounting tabs (1) are fully seated in place.
  2. Connect the power seat switch electrical connector (4).
  3. Install the seat cushion side shield. Refer to SIDE SHIELDS, SEAT CUSHION, FRONT, REMOVAL AND INSTALLATION .
  4. Verify normal operation of the power seat assembly.
