Battery C2 (LHD) Connector End View (D7400B)

Harness-Family: Transmission

Color: NA

Gender: FEMALE

Part Number: R8619-NO

Part Description: Not Available

Connector No: D7400B

Option: LHD

Repair Kit Part Number: Not Serviced

Cavity Count: 1

Fig 1: Battery C2 Connector End View (LHD)
GCWD1296848Courtesy of CHRYSLER
Fig 2: Battery C2 Isometric View (LHD)
GCWD1318556Courtesy of CHRYSLER
Fig 3: Battery C2 Component Location View (LHD)
GCWD1318775Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 A8 RD 35.0 B(+) N/A
