Lamp-Vanity-Left (Standard) Connector End View (D4592A)

Harness-Family: Mirror

Color: BLACK

Gender: MALE

Part Number: 872-658-521

Part Description: Not Available

Connector No: D4592A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 3

Fig 1: Lamp-Vanity-Left Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Lamp-Vanity-Left Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Lamp-Vanity-Left Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Lamp-Vanity-Left Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	M27	YE/BU	0.50	READING LAMPS DRIVER	N/A
2	Z910	BK	0.75	GROUND	N/A
3	G38	GY	0.35	UGDO ENABLE CONTROL CIRCUIT	N/A
