Speaker-Emergency Assistance (Standard) Connector End View (D3243A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 6098-9143

Part Description: Not Available

Connector No: D3243A

Option: Standard

Repair Kit Part Number: 68496348AA

Cavity Count: 2

Fig 1: Speaker-Emergency Assistance Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Speaker-Emergency Assistance Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Speaker-Emergency Assistance Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Speaker-Emergency Assistance Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	X9	GY/DG	0.75	PERSONAL ASSISTANT SAFETY SERVICE SPEAKER (+)	N/A
2	X10	GY/GN	0.75	PERSONAL ASSISTANT SAFETY SERVICE SPEAKER (-)	N/A
