Sensor-Side Impact B Pillar-Left (Standard) Connector End View (D3166A)

Harness-Family: Body

Color: NATURAL

Gender: FEMALE

Part Number: 1-1924067-5

Part Description: Not Available

Connector No: D3166A

Option: Standard

Repair Kit Part Number: 68225152AB

Cavity Count: 2

Fig 1: Sensor-Side Impact B Pillar-Left Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Sensor-Side Impact B Pillar-Left Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Sensor-Side Impact B Pillar-Left Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Sensor-Side Impact B Pillar-Left Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	R13	GN/BG	0.75	LEFT SIDE IMPACT SENSOR 1 SIGNAL	N/A
2	R15	GN/BN	0.75	LEFT SIDE IMPACT SENSOR 1 GROUND	N/A
