Battery C1 (3.6L Gas LHD) Connector End View (D7400A)

Harness-Family: Transmission

Color: NA

Gender: FEMALE

Part Number: R8620

Part Description: Not Available

Connector No: D7400A

Option: 3.6L GAS LHD

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Battery C1 Connector End View (3.6L GAS LHD)
GCWD1007873Courtesy of CHRYSLER
Fig 2: Battery C1 Isometric View (3.6L GAS LHD)
GCWD1009516Courtesy of CHRYSLER
Fig 3: Battery C1 Component Location View (3.6L GAS LHD)
GCWD1318776Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 A1 RD 35.0 FUSED B(+) N/A
