Motor-Seat Adjuster-Rear Driver Vertical (Standard) Connector End View (D3034A)

Harness-Family: Seat_Driver

Color: BLACK

Gender: FEMALE

Part Number: 1379217-3_1379218-2

Part Description: Not Available

Connector No: D3034A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 5

Fig 1: Motor-Seat Adjuster-Rear Driver Vertical Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Motor-Seat Adjuster-Rear Driver Vertical Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Motor-Seat Adjuster-Rear Driver Vertical Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Motor-Seat Adjuster-Rear Driver Vertical Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	P113	GN/WH	2.0	DRIVER SEAT REAR VERTICAL DOWN DRIVER	MEMORY
1	P13	GN/OG	2.0	DRIVER SEAT REAR DOWN DRIVER	EXCEPT MEMORY
2	G492	BU/VT	0.35	DRIVER SEAT REAR VERTICAL SENSOR GROUND	LATE BUILD
4	G402	VT/DB	0.35	DRIVER SEAT REAR VERTICAL POSITION SENSE	LATE BUILD
5	P11	GN/YE	2.0	DRIVER SEAT REAR RISER UP DRIVER	EXCEPT MEMORY
5	P111	GN/YE	2.0	DRIVER SEAT REAR VERTICAL UP DRIVER	MEMORY
