Switch-EVAP System Monitor (Standard) Connector End View (D6623A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 1_928_403_874

Part Description: Not Available

Connector No: D6623A

Option: Standard

Repair Kit Part Number: 05143779AB

Cavity Count: 2

Fig 1: Switch-Evap System Monitor Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Switch-Evap System Monitor Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Switch-Evap System Monitor Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Switch-Evap System Monitor Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	Z934	BK/VT	0.50	GROUND	N/A
2	K108	VT/GY	0.50	EVAP PURGE SOLENOID SENSE	N/A
