Relay-Power Control C3 (Standard) Connector End View (D3157C)

Harness-Family: Aux_Battery_Positive

Color: NA

Gender: FEMALE

Part Number: R8367-6

Part Description: Not Available

Connector No: D3157C

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Relay-Power Control C3 Connector End View (Standard)
GCWD1014371Courtesy of CHRYSLER
Fig 2: Relay-Power Control C3 Isometric View (Standard)
GCWD1013158Courtesy of CHRYSLER
Fig 3: Relay-Power Control C3 Component Location View (Standard)
GCWD1323117Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 A12 RD/BN 2 FUSED B(+) N/A
