Data Link Connector (Standard) Connector End View (D7405A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 179631-2

Part Description: DIAGNOSTIC CONNECTOR OBD-II, PANEL MOUNT

Connector No: D7405A

Option: Standard

Repair Kit Part Number: 05083231AA

Cavity Count: 16

Fig 1: Data Link Connector Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Data Link Connector Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Data Link Connector Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Data Link Connector Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	N0	NA	0	NO CONNECT	N/A
2	N0	NA	0	NO CONNECT	N/A
3	D434	BG	0.50	DIAGNOSTIC CAN IHS (+)	N/A
4	Z937	BK	0.75	GROUND	N/A
5	Z937	BK	0.75	GROUND	N/A
6	D428	BG	0.50	DIAGNOSTIC CAN C (+)	N/A
7	N0	NA	0	NO CONNECT	N/A
8	N0	NA	0	NO CONNECT	N/A
9	N0	NA	0	NO CONNECT	N/A
10	N0	NA	0	NO CONNECT	N/A
11	D433	WH	0.50	DIAGNOSTIC CAN IHS (-)	N/A
12	D478	VT/YE	0.50	DIAGNOSTIC CAN CH (+)	N/A
13	D477	YE/VT	0.50	DIAGNOSTIC CAN CH (-)	N/A
14	D427	YE	0.50	DIAGNOSTIC CAN C (-)	N/A
15	N0	NA	0	NO CONNECT	N/A
16	A910	RD	0.75	FUSED B(+)	N/A
