Sensor-Washer Fluid Level-Front (Standard) Connector End View (D2299A)

Harness-Family: Dash

Color: GRAY

Gender: FEMALE

Part Number: 7287-8378-40

Part Description: Not Available

Connector No: D2299A

Option: Standard

Repair Kit Part Number: 68045333AA

Cavity Count: 2

Fig 1: Sensor-Washer Fluid Level-Front Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Sensor-Washer Fluid Level-Front Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Sensor-Washer Fluid Level-Front Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Sensor-Washer Fluid Level-Front Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	W11	BN/VT	0.50	LOW WASH SW RTN 1	N/A
2	W1	BN/BG	0.35	WASHER SWITCH SENSE	N/A
