Sensor-Humidity (Standard) Connector End View (D2483A)

Harness-Family: Mirror_Int_Jumper

Color: VIOLET

Gender: FEMALE

Part Number: 4-1718346-1

Part Description: Not Available

Connector No: D2483A

Option: Standard

Repair Kit Part Number: Terminal Kits Only

Cavity Count: 3

Fig 1: Sensor-Humidity Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Sensor-Humidity Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Sensor-Humidity Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Sensor-Humidity Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	Z930	BK	0.35	GROUND	N/A
2	D409	WH	0.35	LIN BUS	N/A
3	F948	PK/GN	0.35	FUSED IGNITION	N/A
