Relay-Power Control C2 (Standard) Connector End View (D3157B)

Harness-Family: Dash

Color: NA

Gender: FEMALE

Part Number: R8366-6

Part Description: Not Available

Connector No: D3157B

Option: Standard

Repair Kit Part Number: Not Serviced

Cavity Count: 1

Fig 1: Relay-Power Control C2 Connector End View (Standard)
GCWD1014619Courtesy of CHRYSLER
Fig 2: Relay-Power Control C2 Isometric View (Standard)
GCWD1013182Courtesy of CHRYSLER
Fig 3: Relay-Power Control C2 Component Location View (Standard)
GCWD1322977Courtesy of CHRYSLER
Pin Circuit Wire Color Gauge/Size Function Option
1 A702 RD 2 FUSED B(+) N/A
