Power Outlet-Rear (Standard) Connector End View (D7412C)

Harness-Family: Body

Color: GRAY

Gender: FEMALE

Part Number: 1480-5000

Part Description: LIGHTER OUTLET CONNECTOR ASSEMBLY

Connector No: D7412C

Option: Standard

Repair Kit Part Number: 05019916AB

Cavity Count: 3

Fig 1: Power Outlet-Rear Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Power Outlet-Rear Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Power Outlet-Rear Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Power Outlet-Rear Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	F927	PK/YE	1.5	FUSED IGNITION	N/A
2	N0	NA	0	NO CONNECT	N/A
3	Z943	BK/BU	1.5	GROUND	N/A
