Module-Hands Free Liftgate (Standard) Connector End View (D2945A)

Harness-Family: FASCIA_REAR

Color: BLACK

Gender: FEMALE

Part Number: 805-121-521

Part Description: Not Available

Connector No: D2945A

Option: Standard

Repair Kit Part Number: 68364262AB

Cavity Count: 3

Fig 1: Module-Hands Free Liftgate Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Hands Free Liftgate Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Module-Hands Free Liftgate Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Module-Hands Free Liftgate Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	D402	OG/VT	0.35	LIN BUS CBC 2	N/A
2	A960	RD	0.50	FUSED B(+)	N/A
3	Z923	BK	0.50	GROUND	N/A
