Module-Fuel Pump C1 (Standard) Connector End View (D6602A)

Harness-Family: Body

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 15324787

Part Description: Not Available

Connector No: D6602A

Option: Standard

Repair Kit Part Number: 05013978AA

Cavity Count: 4

Fig 1: Module-Fuel Pump C1 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Fuel Pump C1 Isometric View (Standard)

Courtesy of CHRYSLER

Fig 3: Module-Fuel Pump C1 Wire Insertion View (Standard)

Courtesy of CHRYSLER

Fig 4: Module-Fuel Pump C1 Component Location View (Standard)

Courtesy of CHRYSLER

Pin	Circuit	Wire Color	Gauge/Size	Function	Option
1	N14	VT/BU	2.0	GROUND	N/A
2	G109	BK	0.75	FUEL LEVEL SENSE RETURN	N/A
3	N4	DB/WH	0.75	FUEL LEVEL SENSOR SIGNAL	N/A
4	N13	DB/OG	1.5	FUEL PUMP CONTROL	N/A
