Can FD-1
WARNING: This page is about a different car, the 2021 Jeep Grand Cherokee L. However, it is still accessible from the selected car via links, so may be relevant.
CAN-CHASSIS (CAN-FD-1)
| CAN | CIRCUIT ID | CIRCUIT DESCRIPTION | DOMINANT MODULES | NON-DOMINANT MODULES | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| FD-1 | D280 | CAN FD (+) | Body Control Module (BCM) | Security Gateway Module (SGW) | Air Suspension Control Module (ASCM) | ||||||||
| D281 | CAN FD (-) | [2] [3] | [2] [3] | [1] [3] | |||||||||
| [1] Daisy Chained Module On This CAN. | |||||||||||||
| [2] Module is connected to more than one CAN. | |||||||||||||
| [3] Module has internal Trust-Anchor. | |||||||||||||
For a complete CAN FD-1 BUS SYSTEM wiring diagram, refer to the appropriate system wiring diagram .
