Module, Door (DDM/PDM): Removal

WARNING: This page is about a different car, the 2020 Chrysler 300 and 2019 Chrysler 300. However, it is still accessible from the selected car via links, so may be relevant.
GC0144728Courtesy of CHRYSLER GROUP, LLC
  1. Disconnect and isolate the negative battery cable. If equipped with an Intelligent Battery Sensor (IBS), disconnect the IBS connector first before disconnecting the negative battery cable.
  2. Remove the trim panel from the inside of the front door. Refer to PANEL, DOOR TRIM, REMOVAL .
  3. Disconnect the wire harness connectors (3) from the door control module (2).
  4. Remove the fasteners (4) that secure the door control module to the front door hardware module carrier (1).
  5. Remove the door control module from the door hardware module carrier.
