Module-Light Rain Sensor (Standard) Connector End View (D2683A)

Harness-Family: Mirror_Int_Jumper

Color: BLACK

Gender: FEMALE

Part Number: 1-1718346-1

Part Description: Not Available

Connector No: D2683A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Light Rain Sensor Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Light Rain Sensor Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

F948

PK/GN

0.35

FUSED IGNITION

N/A

Z930

0.35

GROUND

N/A

D401

0.35

LIN BUS 1

N/A

⁽¹⁾	Pins not listed are not used for this connector
