Module-Global TELEMATIC Box C3 (Standard) Connector End View (D335C)

Harness-Family: IP

Color: BORDEAUX

Gender: FEMALE

Part Number: 59Z113-000-D

Part Description: Not Available

Connector No: D335C

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Global Telematic Box C3 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Global Telematic Box C3 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D944

0.82

GPS/SATELLITE RADIO ANTENNA SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
