Can Bus Splice Block 19 (Standard) Connector End View (D3215A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 7283-8850-30_7182-9630-30

Part Description: Not Available

Connector No: D3215A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Can Bus Splice Block 19 Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Can Bus Splice Block 19 Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

BG/WH

0.50

CAN C (+)

N/A

BG/WH

0.50

CAN C (+)

N/A

D305

DB/WH

0.50

CAN C (+)

N/A

0.50

CAN C (-)

N/A

0.50

CAN C (-)

N/A

D306

0.50

CAN C (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
