Module-Heater Control (Standard) Connector End View (D2845A)

Harness-Family: Under_Body

Color: DARK BROWN

Gender: FEMALE

Part Number: F554310

Part Description: Not Available

Connector No: D2845A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Heater Control Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Heater Control Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K403

1.5

DEF TANK HEATER SUPPLY

N/A

K404

1.5

LINE HEATER SUPPLY

N/A

F343

BN/YE

1.0

ASD RELAY OUTPUT

N/A

Z909

1.0

GROUND

N/A

D468

GY/WH

0.50

PRIVATE CAN (-)

N/A

D469

0.50

PRIVATE CAN (+)

N/A

A914

5.0

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
