Module-Steering Column-Lock (Standard) Connector End View (D3925A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 1-1534121-1_1534120-1

Part Description: Not Available

Connector No: D3925A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Steering Column-Lock Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Steering Column-Lock Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

F892

PK/BU

0.75

IGNITION KEY-IN SIGNAL

N/A

Z912

0.75

GROUND

N/A

D410

OG/PK

0.35

LIN KIN

N/A

A910

0.75

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
