Module-Intrusion Transceiver (Standard) Connector End View (D3851A)

Harness-Family: Headliner

Color: BLACK

Gender: FEMALE

Part Number: 2272431-3

Part Description: Not Available

Connector No: D3851A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Module-Intrusion Transceiver Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Module-Intrusion Transceiver Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A990

0.35

FUSED B(+)

N/A

D96

WH/BU

0.50

SIREN SIGNAL CONTROL

N/A

D255

0.35

CAN IHS (+)

N/A

D254

WH/VT

0.35

CAN IHS (-)

N/A

Z924

0.50

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
